Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 83172 |
Part Description | Aluminum Filter Drier w/ Pad Mount |
Body Diameter | 1.375 |
Body Length | 11.000 |
Connector B Type | Pad Mount |
Connector Type | Pad Mount |
Desiccant | Yes |
Desiccant Replaceable | Not Replaceable |
Dia. MM | 34.925 |
Gasket / Seals | Included |
In Line Filter Material | Desiccant |
In Line Filter Outlet Fitting Type | Pad Mount |
Inlet Filter Fitting Type | Pad Mount |
Inlet Fitting Diameter | .482 |
Inlet Fraction | 1/2 |
Length MM | 279.400 |
Material | Aluminum |
Meets / Exceeds OEM | Yes |
Mounting Bracket Included | Hardware not included |
O-Ring A Number/Desc | [24646] / Green Round O/Ring |
Outlet Fitting Type | Pad Mount |
Outlet Fraction | 1/2 |
Outlet IN | .482 |
Overall Depth IN | 11.000 |
Overall Depth MM | 279.400 |
Pad Mount | w/ Pad Mount |
Service Port | w/o Service Port |
Sight Glass | No |
Style | Aluminum Filter Drier w/ Pad Mount |
Switch Port | w/o Switch Port |
UPC | 096361831728 |
Year Make Model | Trim | Engine |
---|---|---|
2010-2018 Mazda 3 | All Trims | All Engines |
2010-2018 Mazda 3 Sport | All Trims | All Engines |
2012-2015 Mazda 5 | All Trims | All Engines |
2014-2019 Mazda 6 | All Trims | All Engines |
2013-2019 Mazda CX-5 | All Trims | All Engines |
2007-2012 Mazda CX-7 | All Trims | All Engines |
