Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 83238 |
Part Description | Accumulator |
Body Diameter | 3.500 |
Body Length | 8.750 |
Dia. MM | 88.900 |
Inlet Fitting Diameter | 3/4 |
Inlet Fitting Type | P-Nut Fitting |
Length MM | 222.250 |
Material | Aluminum |
Meets / Exceeds OEM | Yes |
Mounting Hardware | Hardware not included. |
O-Ring A Number/Desc | [24676] / Green O-Ring |
O-Ring A Quantity | 1 |
O-Ring B Number/Desc | [24404] / Slimline Washer |
O-Ring B Quantity | 2 |
Outlet Fitting Type | P-Nut Fitting |
Outlet Fraction | 1-1/8 |
Style | Complete Unit |
Switch | w/ Switch Port |
Switch Port Dia. IN | 0.472 |
Switch Port Dia.MM | 12.000 |
Switch Service Port | w/ Service Port |
UPC | 096361832381 |
Year Make Model | Trim | Engine |
---|---|---|
2003-2014 Chevrolet Express 1500 | All Trims | All Engines |
2003-2017 Chevrolet Express 2500 | All Trims | All Engines |
2003-2017 Chevrolet Express 3500 | All Trims | All Engines |
2009-2017 Chevrolet Express Cargo | All Trims | All Engines |
2009-2017 Chevrolet Express Pasajeros | All Trims | All Engines |
2003-2014 GMC Savana 1500 | All Trims | All Engines |
2003-2017 GMC Savana 2500 | All Trims | All Engines |
2003-2017 GMC Savana 3500 | All Trims | All Engines |
