Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 56972 |
Part Description | A C Suction And Liquid Line Hose Assembly |
Bracket | w/ Bracket |
End 1 Type | P-Nut Fitting |
End 2 Type | Sealing Washer |
Fittings Included | Included |
Gasket or Seal Included | Included |
Liquid Line Gender | Male |
Liquid Line Style | Sealing Washer |
Manifold | Yes |
Material | Aluminum / Rubber |
Muffler | w/ Muffler |
O-Ring A Number/Desc | [24401] / Slim Line Sealing Washer |
O-Ring A Quantity | 2 |
O-Ring B Number/Desc | [24404] / Slimline Washer |
O-Ring B Quantity | 2 |
O.E. Replacement | Yes |
Orifice Tube | w/o Orifice Tube |
Refrigerant Type | R134-A |
Service Port | w/o Service Port |
Style | Hose Assy /Suction, Liquid |
Suction End Size | No. 12 |
Suction End Type | Male P-Nut |
Switch Service Port | w/o Switch Port |
System Pressure | High Pressure / Low Pressure |
UPC | 096361072626 |
Year Make Model | Trim | Engine |
---|---|---|
2010 Ford Fusion | All Trims | 6 Cyl 3.0L |
2010-2012 Ford Fusion | All Trims | 4 Cyl 2.5L |
2010 Mercury Milan | All Trims | 6 Cyl 3.0L |
2010-2011 Mercury Milan | All Trims | 4 Cyl 2.5L |
