Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 83256 |
Part Description | A C Receiver Drier |
Body Diameter | 2.250 |
Body Length | 6.125 |
Bracket | w/ Bracket |
Connector B Type | Pad Mount |
Connector Type | P-Nut |
Desiccant | Yes |
Desiccant Replaceable | Not Replaceable |
Dia. MM | 57.150 |
Gasket / Seals | Included |
In Line Filter Material | Desiccant |
In Line Filter Outlet Fitting Type | P-Nut |
Inlet Filter Fitting Type | P-Nut |
Inlet Fitting Diameter | .337 |
Inlet Fitting Type | P-Nut Fitting |
Length MM | 155.575 |
Material | Aluminum |
Meets / Exceeds OEM | Yes |
Mounting Bracket Included | Hardware not included |
O-Ring A Number/Desc | [24401] / Slim Line Sealing Washer |
O-Ring A Quantity | 2 |
Outlet Fitting Type | Pad Mount |
Outlet IN | .669 |
Overall Depth IN | 6.125 |
Pad Mount | w/o Pad Mount |
Service Port | w/o Service Port |
Sight Glass | No |
Style | Aluminum Filter Drier w/o Pad Mount |
Switch Port | w/o Switch Port |
UPC | 096361832565 |
Year Make Model | Trim | Engine |
---|---|---|
2003-2011 Saab 9-3 | All Trims | All Engines |
2010-2011 Saab 9-3X | All Trims | All Engines |
