Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 33366 |
Part Description | A C Receiver Drier |
Body Diameter | 2.000 |
Body Length | 8.750 |
Bracket | w/o Bracket |
Connector B Type | Female O-Ring |
Connector Type | Male Insert O-Ring |
Desiccant | Yes |
Desiccant Replaceable | Not Replaceable |
Dia. MM | 50.800 |
Fuse Plug | No |
Gasket / Seals | Included |
In Line Filter Material | Desiccant |
In Line Filter Outlet Fitting Type | Female |
Inlet Filter Fitting Thread Diameter | 0.625 |
Inlet Filter Fitting Type | Female |
Inlet Fitting Diameter | 0.375 |
Inlet Fitting Type | Male Insert O-Ring |
Inlet Fraction | 3/8 |
Inlet IN | 0.375 |
Inlet MM | 9.525 |
Length MM | 222.250 |
Material | Steel |
Meets / Exceeds OEM | Yes |
Moisture Indicator Window | No |
Mounting Bracket Included | Hardware not included |
O-Ring A Number/Desc | [24606] / Green O-Ring |
O-Ring A Quantity | 2 |
Outlet Fitting Type | Female O-Ring |
Outlet Fraction | 3/8 |
Outlet IN | 0.375 |
Outlet MM | 9.525 |
Overall Depth IN | 11.000 |
Overall Depth MM | 279.400 |
P. R. V. | No |
Service Port | w/o Service Port |
Sight Glass | No |
Stud | No |
Style | Steel Filter Drier |
Switch Port | w/o Switch Port |
UPC | 096361333666 |
Year Make Model | Trim | Engine |
---|---|---|
1978 Ford Bronco | All Trims | All Engines |
1972-1973 Ford F-100 | All Trims | All Engines |
1978 Ford F-100 | All Trims | 8 Cyl 5.0L |
1978 Ford F-100 | All Trims | 8 Cyl 5.8L |
1978 Ford F-100 | All Trims | 8 Cyl 6.6L |
1978 Ford F-150 | All Trims | 8 Cyl 5.0L |
1978 Ford F-150 | All Trims | 8 Cyl 5.8L |
1978 Ford F-150 | All Trims | 8 Cyl 6.6L |
1978 Ford F-150 | All Trims | 8 Cyl 7.5L |
1972-1973 Ford F-250 | All Trims | All Engines |
