Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 33363 |
Part Description | A C Receiver Drier |
Body Diameter | 2.500 |
Body Length | 6.000 |
Bracket | w/o Bracket |
Connector B Type | Female O-Ring |
Connector Type | Male Insert O-Ring |
Desiccant | Yes |
Desiccant Replaceable | Not Replaceable |
Dia. MM | 63.500 |
Fuse Plug | Yes |
Gasket / Seals | Included |
In Line Filter Material | Desiccant |
In Line Filter Outlet Fitting Type | Female |
Inlet Filter Fitting Thread Diameter | 0.625 |
Inlet Filter Fitting Type | Female |
Inlet Fitting Diameter | 0.375 |
Inlet Fitting Type | Male Insert O-Ring |
Inlet Fraction | 3/8 |
Inlet IN | 0.375 |
Inlet MM | 9.525 |
Length MM | 152.400 |
Material | Steel |
Meets / Exceeds OEM | Yes |
Moisture Indicator Window | No |
Mounting Bracket Included | Hardware not included |
O-Ring A Number/Desc | [24610] / Green O-Ring |
O-Ring A Quantity | 1 |
O-Ring B Number/Desc | [24650] / Green O-Ring |
O-Ring B Quantity | 1 |
O-Ring C Number/Desc | [24606] / Green O-Ring |
O-Ring C Quantity | 2 |
Outlet Fitting Type | Female O-Ring |
Outlet Fraction | 3/8 |
Outlet IN | 0.375 |
Outlet MM | 9.525 |
Overall Depth IN | 7.625 |
Overall Depth MM | 193.675 |
P. R. V. | No |
Service Port | w/o Service Port |
Sight Glass | Yes |
Stud | No |
Style | Steel Filter Drier |
Switch Port | w/ Switch Port |
Switch Port Dia. IN | 0.250 |
Switch Port Dia.MM | 6.350 |
UPC | 096361333635 |
Year Make Model | Trim | Engine |
---|---|---|
1980-1987 Audi 4000 | All Trims | All Engines |
1984-1987 Audi 4000 Quattro | All Trims | All Engines |
1981-1987 Audi Coupe | All Trims | All Engines |
1975-1979 Audi Fox | All Trims | All Engines |
1983-1985 Audi Quattro | All Trims | 5 Cyl 2.2L |
1988-1989 Eagle Medallion | All Trims | All Engines |
1994-1995 Land Rover Defender 90 | All Trims | All Engines |
1997 Land Rover Defender 90 | All Trims | All Engines |
1980-1986 Peugeot 505 | All Trims | All Engines |
1980 Peugeot 604 | All Trims | 6 Cyl 2.8L |
