Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 33258 |
Part Description | A C Receiver Drier |
Body Diameter | 2.500 |
Body Length | 8.500 |
Bracket | w/o Bracket |
Connector B Type | Male Flare |
Connector Type | Male Flare |
Desiccant | Yes |
Desiccant Replaceable | Not Replaceable |
Dia. MM | 63.500 |
Gasket / Seals | Included |
In Line Filter Material | Desiccant |
In Line Filter Outlet Fitting Type | Male |
Inlet Filter Fitting Thread Diameter | 0.625 |
Inlet Filter Fitting Type | Male |
Inlet Fitting Diameter | 0.375 |
Inlet Fitting Type | Flare Fitting |
Inlet Fraction | 3/8 |
Inlet IN | 0.375 |
Inlet MM | 9.525 |
Length MM | 215.900 |
Material | Steel |
Meets / Exceeds OEM | Yes |
Moisture Indicator Window | No |
Mounting Bracket Included | Hardware not included |
New or Reman | New |
O-Ring A Number/Desc | [24650] / Green O-Ring |
O-Ring A Quantity | 1 |
O-Ring B Number/Desc | [24606] / Green O-Ring |
O-Ring B Quantity | 1 |
Outlet Fitting Type | Flare Fitting |
Outlet Fraction | 3/8 |
Outlet IN | 0.375 |
Outlet MM | 9.525 |
Overall Depth IN | 8.500 |
P. R. V. | No |
Service Port | w/ Service Port |
Sight Glass | No |
Stud | No |
Style | Steel Filter Drier |
Switch Port | w/ Switch Port |
Switch Port Dia. IN | 0.250 |
Switch Port Dia.MM | 6.350 |
Switch Port Size | 3/8 |
UPC | 096361332584 |
Year Make Model | Trim | Engine |
---|---|---|
1982 Chrysler LeBaron | All Trims | All Engines |
1982-1983 Dodge 400 | All Trims | All Engines |
1983 Dodge 600 | All Trims | All Engines |
1981-1983 Dodge Aries | All Trims | All Engines |
1981-1983 Dodge Challenger | All Trims | All Engines |
1981-1982 Dodge D50 | All Trims | All Engines |
1983 Dodge Power Ram 50 | All Trims | All Engines |
1983 Dodge Ram 50 | All Trims | All Engines |
1977 Mazda B1800 | All Trims | All Engines |
1970-1971 Mazda R100 | All Trims | All Engines |
