Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 56826 |
Part Description | A C Liquid Line Hose Assembly |
Bracket | w/o Bracket |
Fittings Included | Included |
Gasket or Seal Included | Included |
Liquid Line Style | P-Nut Fitting |
Material | Aluminum / Rubber |
O-Ring A Number/Desc | [24149] / Gasket |
O-Ring A Quantity | 1 |
O-Ring B Number/Desc | [24661] / Green O-Ring |
O-Ring B Quantity | 1 |
O-Ring C Number/Desc | [24083] / Green O-Ring |
O-Ring C Quantity | 1 |
O.E. Replacement | Yes |
Orifice Tube | w/ Orifice Tube |
Refrigerant Type | R134-A |
Service Port | w/ Service Port |
Service Port Size | 13 mm |
Service Port Type | R134-A Quick Disconnect |
Style | Liquid Line Hose Assembly w/ Captured Orifice Tube |
Suction End Type | P-Nut Fitting |
Sve Port Low Side | Low Side |
Switch Service Port | w/o Switch Port |
UPC | 096361568266 |
Year Make Model | Trim | Engine |
---|---|---|
2003-2005 Dodge Neon | All Trims | 4 Cyl 2.0L |
2003-2005 Dodge SX 2.0 | All Trims | All Engines |
