Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 54809 |
Part Description | A C Evaporator Core |
Core Depth Fraction | 2-7/8 or 3 |
Core Depth MM | 73.025 or 76.200 |
Core Height Fraction | 7-1/2 or 7-3/8 |
Core Height MM | 187.325 or 190.500 |
Core Width Fraction | 8 or 8-7/8 |
Core Width MM | 203.200 or 225.425 |
Depth | 2.875 or 3.000 |
Height | 7.375 or 7.500 |
Inlet Fitting Outside Diameter | No. 8 |
Inlet Fitting Type | Block Fitting |
Material | Aluminum |
O-Ring A Number/Desc | [24622] / Green O-Ring |
O-Ring A Quantity | 1 |
O-Ring B Number/Desc | [24649] / Green O-Ring |
O-Ring B Quantity | 1 |
Outlet Fitting Outside Diameter | No. 12 |
UPC | 096361548091 |
Width | 8.000 or 8.875 |
Year Make Model | Trim | Engine |
---|---|---|
2001-2002 Chrysler Grand Voyager | All Trims | All Engines |
2001-2005 Chrysler Town & Country | All Trims | All Engines |
2001-2003 Chrysler Voyager | All Trims | All Engines |
2001-2005 Dodge Caravan | All Trims | All Engines |
2001-2005 Dodge Grand Caravan | All Trims | All Engines |
