Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 55502 |
Part Description | A C Discharge And Liquid Line Hose Assembly |
Bracket | w/o Bracket |
Discharge End Type | Block |
Fittings Included | Included |
Gasket or Seal Included | Included |
Liquid Line Style | Block |
Manifold | w/ Manifold |
Material | Aluminum / Rubber |
Muffler | w/ Muffler |
O-Ring A Number/Desc | [24606] / Green O-Ring |
O-Ring A Quantity | 1 |
O-Ring B Number/Desc | [24661] / Green O-Ring |
O-Ring B Quantity | 2 |
O-Ring C Number/Desc | [24124] / Filter Drier Flange Port Gasket |
O-Ring C Quantity | 1 |
O-Ring D Number/Desc | [24139] / Condenser Block Fitting Port Gasket |
O-Ring D Quantity | 1 |
O.E. Replacement | Yes |
Orifice Tube | Not Included |
Refrigerant Type | R134a |
Service Port | w/o Service Port |
Style | Hose Assy /Discharge, Liquid |
Suction End Size | No. 8 |
Suction End Style | Block |
Suction End Type | Block |
Switch Port Quantity | 1 |
Switch Port Size | 3/8" - 24 |
Switch Service Port | w/ Switch Port |
System Pressure | High Pressure |
UPC | 096361555020 |
Year Make Model | Trim | Engine |
---|---|---|
1985-1989 Chrysler Daytona | All Trims | All Engines |
1984-1986 Chrysler Laser | All Trims | All Engines |
1985 Chrysler LeBaron | All Trims | 4 Cyl 2.2L |
1986-1989 Chrysler LeBaron | All Trims | All Engines |
1989 Chrysler LeBaron | All Trims | 4 Cyl 2.2L |
1989 Chrysler LeBaron | All Trims | 4 Cyl 2.5L |
1983-1985 Chrysler New Yorker | All Trims | 4 Cyl 2.2L |
1986-1988 Chrysler New Yorker | All Trims | All Engines |
1989 Chrysler TC Maserati | All Trims | All Engines |
1985 Chrysler Town & Country | All Trims | 4 Cyl 2.2L |
