Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 98664 |
Part Description | A C Compressor With Clutch |
Clutch Included | Yes |
Clutch Maximum Diameter | 4.515625 |
Coil Clock Position | Wire Lead |
Coil Voltage | 12 |
Compatible Refrigerant Oil Type | PAG 46 |
Compressor Type | VCS-14EC |
Discharge Port Type | O-Ring |
Distance From Clutch To Mounting Flange | 1.625 |
ECV Harness Connector | SE12F, 26896 Female / / SE12M, 26880 Male |
Mount Distance MM | 41.148 |
Mounting Hardware | Not Included |
Mounting Type | Tangent Mount |
New or Reman | New |
O-Ring A Number/Desc | [24602] / Green Round O-Ring |
O-Ring A Quantity | 1 |
O-Ring B Number/Desc | [24659] / Green O-Ring |
O-Ring B Quantity | 1 |
Pulley Belt Type | Serpentine |
Pulley Diameter MM | 114.808 |
Pulley Groove Quantity | 6 |
Pulley Lip Diameter | 4.515625 |
Pulley Outside Diameter | 4.515625 |
Pulley Ridge Diameter | 4.515625 |
Refrigerant Type | R134a |
Suction Port Type | O-Ring |
Terminal Type | Pin |
UPC | 096361986640 |
Year Make Model | Trim | Engine |
---|---|---|
2014-2017 Infiniti QX60 | All Trims | 4 Cyl 2.5L |
2013-2014 Nissan Altima | SL | 4 Cyl 2.5L |
2013-2014 Nissan Altima | SV | 4 Cyl 2.5L |
2013-2017 Nissan Altima | All Trims | 4 Cyl 2.5L |
2018 Nissan Altima | SL | 4 Cyl 2.5L |
2018 Nissan Altima | SV | 4 Cyl 2.5L |
2014 Nissan Pathfinder | All Trims | 4 Cyl 2.5L |
2014-2016 Nissan Rogue | All Trims | All Engines |
2017-2018 Nissan Rogue | All Trims | 4 Cyl 2.5L |
2014-2015 Nissan Rogue Select | All Trims | All Engines |
