Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 98379 |
Part Description | A C Compressor With Clutch |
Clutch Included | Yes |
Clutch Maximum Diameter | 4.71875 |
Coil Clock Position | Lead Wire |
Coil Voltage | 12 |
Compatible Refrigerant Oil Type | PAG 46 |
Compressor Type | 7SEU17C |
Discharge Port Type | O-Ring |
Distance From Clutch To Mounting Flange | 1.46875 |
ECV Harness Connector | SE35F, 26901 Female / / SE35M, 26887 Male |
Mount Distance MM | 37.000 |
Mounting Hardware | Not Included |
Mounting Type | 3 Tangent One on Rear Head |
New or Reman | New |
O-Ring A Number/Desc | [24635] / Green Round O-Ring |
O-Ring A Quantity | 1 |
O-Ring B Number/Desc | 24659 |
O-Ring B Quantity | 1 |
O-Ring C Number/Desc | 24683 |
O-Ring C Quantity | 1 |
Printed Foot Note | May Require use of OE Manifold |
Pulley Belt Type | Serpentine |
Pulley Diameter MM | 119.888 |
Pulley Groove Quantity | 7 |
Pulley Lip Diameter | 4.71875 |
Pulley Outside Diameter | 4.71875 |
Pulley Ridge Diameter | 4.71875 |
Refrigerant Type | R134a |
Suction Port Type | O-Ring |
Terminal Type | Pin |
UPC | 096361983793 |
Year Make Model | Trim | Engine |
---|---|---|
2007 Audi A8 Quattro | All Trims | 12 Cyl 6.0L |
2009 Audi A8 Quattro | All Trims | 12 Cyl 6.0L |
2005-2006 Porsche Cayenne | All Trims | 6 Cyl 3.2L |
2008-2010 Porsche Cayenne | All Trims | 6 Cyl 3.6L |
2008-2010 Porsche Cayenne | Base | 6 Cyl 3.6L |
2017 Porsche Cayenne | All Trims | 6 Cyl 3.6L |
2018 Porsche Cayenne | Base | 6 Cyl 3.6L |
2018 Porsche Cayenne | Platinum Edition | 6 Cyl 3.6L |
2002-2004 Volkswagen Passat | All Trims | 8 Cyl 4.0L |
2004-2006 Volkswagen Phaeton | All Trims | 12 Cyl 6.0L |
