Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 98377 |
Part Description | A C Compressor With Clutch |
Clutch Included | Yes |
Clutch Maximum Diameter | 4.3125 |
Coil Clock Position | Wire Lead |
Coil Voltage | 12 |
Compatible Refrigerant Oil Type | PAG 46 |
Compressor Type | 7SBU16C |
Discharge Port Type | O-Ring |
Distance From Clutch To Mounting Flange | 1.0625 |
Mount Distance MM | 26.924 |
Mounting Hardware | Not Included |
Mounting Type | Tangent Mount |
New or Reman | New |
O-Ring A Number/Desc | [24659] / Green O-Ring |
O-Ring A Quantity | 1 |
O-Ring B Number/Desc | [24635] / Green Round O-Ring |
O-Ring B Quantity | 1 |
Printed Foot Note | May Require use of OE Manifold |
Pulley Belt Type | Serpentine |
Pulley Diameter MM | 109.525 |
Pulley Groove Quantity | 4 |
Pulley Lip Diameter | 4.3125 |
Pulley Outside Diameter | 4.3125 |
Pulley Ridge Diameter | 4.3125 |
Refrigerant Type | R134a |
Suction Port Type | O-Ring |
Terminal Type | Pin |
UPC | 096361983779 |
Year Make Model | Trim | Engine |
---|---|---|
2003 BMW 325Ci | All Trims | All Engines |
2003 BMW 325i | All Trims | All Engines |
2003 BMW 325xi | All Trims | All Engines |
2003-2006 BMW 330Ci | All Trims | All Engines |
2003-2006 BMW 330i | All Trims | All Engines |
2003-2006 BMW 330xi | All Trims | All Engines |
2004-2005 BMW X3 | All Trims | 6 Cyl 2.5L |
2004-2006 BMW X3 | All Trims | 6 Cyl 3.0L |
