Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 98356 |
Part Description | A C Compressor With Clutch |
Clutch Included | Yes |
Clutch Maximum Diameter | 4.000 |
Coil Clock Position | NR |
Coil Voltage | 12 |
Compatible Refrigerant Oil Type | PAG 46 |
Compressor Type | 7SEU17C |
Discharge Port Type | O-Ring |
Distance From Clutch To Mounting Flange | 0.671875 |
ECV Harness Connector | SE05F, 26892 Female / / SE22M, 26882 Male |
Mount Distance MM | 17.018 |
Mounting Hardware | Not Included |
Mounting Type | Tangent Mount |
New or Reman | New |
O-Ring A Number/Desc | [24670] / Green O-Ring |
O-Ring A Quantity | 1 |
O-Ring B Number/Desc | [24635] / Green Round O-Ring |
O-Ring B Quantity | 1 |
Printed Foot Note | May Require use of OE Manifold |
Pulley Belt Type | Serpentine |
Pulley Diameter MM | 101.600 |
Pulley Groove Quantity | 6 |
Pulley Lip Diameter | 4.000 |
Pulley Outside Diameter | 4.000 |
Pulley Ridge Diameter | 4.000 |
Refrigerant Type | R134a |
Suction Port Type | O-Ring |
Terminal Type | Pin |
UPC | 096361983564 |
Year Make Model | Trim | Engine |
---|---|---|
2000 Mercedes-Benz C230 | All Trims | All Engines |
2001-2002 Mercedes-Benz C240 | All Trims | All Engines |
2004-2005 Mercedes-Benz C240 | All Trims | All Engines |
2000 Mercedes-Benz C280 | All Trims | All Engines |
2002-2003 Mercedes-Benz C32 AMG | All Trims | All Engines |
2001-2005 Mercedes-Benz C320 | All Trims | All Engines |
2006-2007 Mercedes-Benz C350 | All Trims | All Engines |
2000 Mercedes-Benz C43 AMG | All Trims | All Engines |
2003-2009 Mercedes-Benz CL500 | All Trims | All Engines |
2010-2011 Mercedes-Benz CL500 | All Trims | 12 Cyl 5.5L |
