Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 98322 |
Part Description | A C Compressor With Clutch |
Clutch Included | Yes |
Clutch Maximum Diameter | 4.46875 |
Coil Clock Position | Wire Lead |
Coil Voltage | 12 |
Compatible Refrigerant Oil Type | See under hood decal for proper oil type. |
Compressor Type | HCC-RS20 |
Discharge Port Type | O-Ring |
Distance From Clutch To Mounting Flange | 1.859375 |
Mount Distance MM | 47.244 |
Mounting Hardware | Not Included |
Mounting Type | Tangent Mount |
New or Reman | New |
O-Ring A Number/Desc | [24241] / Sealing Washer Kit |
O-Ring A Quantity | 1 |
O-Ring B Number/Desc | [24243] / Tear Drop Sealing Washer |
O-Ring B Quantity | 1 |
Pulley Belt Type | Serpentine |
Pulley Diameter MM | 113.284 |
Pulley Groove Quantity | 8 |
Pulley Lip Diameter | 4.46875 |
Pulley Outside Diameter | 4.46875 |
Pulley Ridge Diameter | 4.46875 |
Refrigerant Type | R-134a or R1234yf |
Suction Port Type | O-Ring |
Terminal Type | Pin |
UPC | 096361983229 |
Year Make Model | Trim | Engine |
---|---|---|
2011-2016 Ford F-250 Super Duty | All Trims | 8 Cyl 6.7L |
2011-2016 Ford F-350 Super Duty | All Trims | 8 Cyl 6.7L |
