Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 98311 |
Part Description | A C Compressor With Clutch |
Clutch Included | Yes |
Clutch Maximum Diameter | 4.703125 |
Coil Clock Position | 1 |
Coil Voltage | 12 |
Compatible Refrigerant Oil Type | See under hood decal for proper oil type. |
Compressor Type | HCC-RS18 |
Discharge Port Type | O-Ring / Gasket |
Distance From Clutch To Mounting Flange | 1.53125 |
Mount Distance MM | 38.862 |
Mounting Hardware | Not Included |
Mounting Type | Tangent Mount |
New or Reman | New |
O-Ring A Number/Desc | [24068] / Gasket |
O-Ring A Quantity | 1 |
O-Ring B Number/Desc | [24069] / Gasket |
O-Ring B Quantity | 1 |
Pulley Belt Type | Serpentine |
Pulley Diameter MM | 119.380 |
Pulley Groove Quantity | 6 |
Pulley Lip Diameter | 4.703125 |
Pulley Outside Diameter | 4.703125 |
Pulley Ridge Diameter | 4.703125 |
Refrigerant Type | R-134a or R1234yf |
Suction Port Type | O-Ring / Gasket |
Terminal Type | Pin |
UPC | 096361983113 |
Year Make Model | Trim | Engine |
---|---|---|
2011-2013 Chrysler 300 | All Trims | 6 Cyl 3.6L |
2011-2014 Dodge Challenger | All Trims | 6 Cyl 3.6L |
2011-2013 Dodge Charger | All Trims | 6 Cyl 3.6L |
2011-2015 Dodge Durango | All Trims | 6 Cyl 3.6L |
2011-2015 Jeep Grand Cherokee | All Trims | 6 Cyl 3.6L |
2016 Jeep Grand Cherokee | All Trims | 6 Cyl 3.0L |
