Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 78664 |
Part Description | A C Compressor With Clutch |
Clutch Included | Yes |
Clutch Maximum Diameter | 4.515625 |
Coil Clock Position | Wire Lead |
Coil Voltage | 12 |
Compatible Refrigerant Oil Type | PAG 46 |
Compressor Type | SP17 |
Discharge Port Type | O-Ring |
Distance From Clutch To Mounting Flange | 1.625 |
Mount Distance MM | 41.148 |
Mounting Hardware | Not Included |
Mounting Type | Tangent Mount |
New or Reman | New |
O-Ring A Number/Desc | [24659] / Green O-Ring |
O-Ring A Quantity | 1 |
O-Ring B Number/Desc | [24602] / Green Round O-Ring |
O-Ring B Quantity | 1 |
Pulley Belt Type | Serpentine |
Pulley Diameter MM | 114.808 |
Pulley Groove Quantity | 6 |
Pulley Lip Diameter | 4.515625 |
Pulley Outside Diameter | 4.515625 |
Pulley Ridge Diameter | 4.515625 |
Refrigerant Type | R134a |
Suction Port Type | O-Ring |
Terminal Type | Pin |
UPC | 096361786646 |
w/ Diode | No |
Year Make Model | Trim | Engine |
---|---|---|
2013-2014 Nissan Altima | Base | 4 Cyl 2.5L |
2013-2014 Nissan Altima | S | 4 Cyl 2.5L |
2015-2017 Nissan Altima | All Trims | 4 Cyl 2.5L |
2018 Nissan Altima | S | 4 Cyl 2.5L |
2018 Nissan Altima | SR | 4 Cyl 2.5L |
