Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 68572 |
Part Description | A C Compressor With Clutch |
Clutch Included | Yes |
Clutch Maximum Diameter | 4.750 |
Coil Clock Position | Wire Lead |
Coil Voltage | 12 |
Compatible Refrigerant Oil Type | PAG 100 |
Compressor Type | SD7B10 |
Discharge Port Type | O-Ring |
Distance From Clutch To Mounting Flange | 1.15625 |
Mount Distance MM | 29.210 |
Mounting Hardware | Not Included |
Mounting Type | Ear Mount |
New or Reman | New |
O-Ring A Number/Desc | [24681] / Green O-Ring |
O-Ring A Quantity | 1 |
O-Ring B Number/Desc | [24661] / Green O-Ring |
O-Ring B Quantity | 1 |
Pulley Belt Type | Serpentine |
Pulley Diameter MM | 120.650 |
Pulley Groove Quantity | 4 |
Pulley Lip Diameter | 4.750 |
Pulley Outside Diameter | 4.750 |
Pulley Ridge Diameter | 4.750 |
Refrigerant Type | R134a |
Suction Port Type | O-Ring |
Terminal Type | Pin |
UPC | 096361685727 |
Year Make Model | Trim | Engine |
---|---|---|
1998 Chevrolet Tracker | All Trims | All Engines |
1995-1997 Geo Tracker | All Trims | All Engines |
1995 Suzuki Sidekick | All Trims | All Engines |
1996-1998 Suzuki Sidekick | All Trims | 4 Cyl 1.6L |
