Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 68498 |
Part Description | A C Compressor With Clutch |
Clutch Included | Yes |
Clutch Maximum Diameter | 4.328125 |
Coil Clock Position | Wire Lead |
Coil Voltage | 12 |
Compatible Refrigerant Oil Type | PAG 46 |
Compressor Type | SS96D2 |
Discharge Port Type | O-Ring |
Distance From Clutch To Mounting Flange | 0.5625 |
Mount Distance MM | 14.224 |
Mounting Hardware | Not Included |
Mounting Type | Ear Mount |
New or Reman | New |
O-Ring A Number/Desc | [24608] / Green O-Ring |
O-Ring A Quantity | 1 |
O-Ring B Number/Desc | [24610] / Green O-Ring |
O-Ring B Quantity | 1 |
Pulley Belt Type | Serpentine |
Pulley Diameter MM | 109.982 |
Pulley Groove Quantity | 5 |
Pulley Lip Diameter | 4.328125 |
Pulley Outside Diameter | 4.328125 |
Pulley Ridge Diameter | 4.328125 |
Refrigerant Type | R134a |
Suction Port Type | O-Ring |
Switch Included | Heat Sensor |
Terminal Type | Bullet |
UPC | 096361684980 |
Year Make Model | Trim | Engine |
---|---|---|
1998-1999 BMW 323i | All Trims | All Engines |
1998-1999 BMW 323is | All Trims | All Engines |
1999 BMW 323ti | All Trims | All Engines |
1996-1999 BMW 328i | All Trims | All Engines |
1996-1999 BMW 328is | All Trims | All Engines |
1997-2000 BMW Z3 | All Trims | 6 Cyl 2.8L |
1998-2000 BMW Z3 | All Trims | 6 Cyl 3.2L |
1999-2000 BMW Z3 | All Trims | 6 Cyl 2.5L |
