Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 68271 |
Part Description | A C Compressor With Clutch |
Belt Width IN | 0.500 |
Belt Width MM | 12.700 |
Clutch Included | Yes |
Clutch Maximum Diameter | 5.203125 |
Coil Clock Position | Lead Wire |
Coil Voltage | 12 |
Compatible Refrigerant Oil Type | PAG 150 |
Compressor Type | V5 |
Distance From Clutch To Mounting Flange | 1.6875 |
Mount Distance MM | 42.672 |
Mounting Hardware | Not Included |
Mounting Type | Direct Mount |
New or Reman | New |
O-Ring A Number/Desc | 24354 |
O-Ring A Quantity | 2 |
O-Ring B Number/Desc | Not Required |
O-Ring B Quantity | NR |
O-Ring C Number/Desc | Not Required |
O-Ring C Quantity | NR |
Pulley Belt Type | V-Belt |
Pulley Diameter MM | 132.080 |
Pulley Groove Quantity | 1 |
Pulley Lip Diameter | 5.203125 |
Pulley Outside Diameter | 5.203125 |
Pulley Ridge Diameter | 5.203125 |
Refrigerant Type | R134a |
Terminal Type | Pin |
UPC | 096361682719 |
Year Make Model | Trim | Engine |
---|---|---|
1999-2001 Daewoo Lanos | All Trims | 4 Cyl 1.6L |
2002 Daewoo Lanos | All Trims | All Engines |
