Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 58967 |
Part Description | A C Compressor With Clutch |
Clutch Included | Yes |
Clutch Maximum Diameter | 5.500 |
Coil Clock Position | 2 |
Coil Voltage | 12 |
Compatible Refrigerant Oil Type | PAG 150 |
Compressor Type | DA6, HR6, HE6 |
Discharge Port Type | Sealing Washer |
Distance From Clutch To Mounting Flange | 0.59375 |
Mount Distance MM | 15.240 |
Mounting Hardware | Not Included |
Mounting Type | Type III |
New or Reman | New |
O-Ring A Number/Desc | [24354] / Sealing Washer |
O-Ring A Quantity | 2 |
O-Ring B Number/Desc | Not Required |
O-Ring B Quantity | NR |
O-Ring C Number/Desc | Not Required |
O-Ring C Quantity | NR |
Pulley Belt Type | Serpentine |
Pulley Diameter MM | 139.700 |
Pulley Groove Quantity | 6 |
Pulley Lip Diameter | 5.500 |
Pulley Outside Diameter | 5.500 |
Pulley Ridge Diameter | 5.500 |
Refrigerant Type | R134a |
Suction Port Type | Sealing Washer |
Terminal Type | 8mm Pin Connector |
UPC | 096361589674 |
Year Make Model | Trim | Engine |
---|---|---|
1990-1993 Buick Century | All Trims | 6 Cyl 3.3L |
1989-1990 Buick Electra | All Trims | 6 Cyl 3.8L |
1989-1994 Buick LeSabre | All Trims | 6 Cyl 3.8L |
1991-1994 Buick Park Avenue | All Trims | All Engines |
1989-1991 Buick Reatta | All Trims | All Engines |
1990-1993 Buick Regal | All Trims | 6 Cyl 3.8L |
1989-1993 Buick Riviera | All Trims | All Engines |
1992-1993 Chevrolet Lumina APV | All Trims | 6 Cyl 3.8L |
1992-1994 Oldsmobile 88 | All Trims | All Engines |
1989-1994 Oldsmobile 98 | All Trims | All Engines |
