Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 58955 |
Part Description | A C Compressor With Clutch |
Clutch Included | Yes |
Clutch Maximum Diameter | 5.000 |
Coil Clock Position | 10 |
Coil Voltage | 12 |
Compatible Refrigerant Oil Type | PAG 150 |
Compressor Type | HD6 |
Distance From Clutch To Mounting Flange | 0.59375 |
Mounting Hardware | Not Included |
Mounting Type | Type XIII (All Ears No Threads) |
New or Reman | New |
O-Ring A Number/Desc | [24354] / Sealing Washer |
O-Ring A Quantity | 2 |
O-Ring B Number/Desc | Not Required |
O-Ring B Quantity | NR |
O-Ring C Number/Desc | Not Required |
O-Ring C Quantity | NR |
Pulley Belt Type | Serpentine |
Pulley Diameter MM | 127.000 |
Pulley Groove Quantity | 6 |
Pulley Lip Diameter | 5.000 |
Pulley Outside Diameter | 5.000 |
Pulley Ridge Diameter | 5.000 |
Refrigerant Type | R134a |
Suc Prt Typ Note | R134A - V |
Suction Port Type | Sealing Washer |
Terminal Type | 8mm Pin Connector |
UPC | 096361589551 |
Year Make Model | Trim | Engine |
---|---|---|
1994-1996 Buick Commercial Chassis | All Trims | 8 Cyl 5.7L |
1994-1996 Buick Roadmaster | All Trims | 8 Cyl 5.7L |
1994-1996 Cadillac Commercial Chassis | Base | All Engines |
1994-1996 Cadillac Commercial Chassis | Brougham | All Engines |
1994-1996 Cadillac Fleetwood | All Trims | All Engines |
1993-1994 Chevrolet Camaro | All Trims | All Engines |
1995 Chevrolet Camaro | All Trims | 6 Cyl 3.4L |
1995-1997 Chevrolet Camaro | All Trims | 8 Cyl 5.7L |
1994-1996 Chevrolet Caprice | All Trims | All Engines |
1994 Chevrolet Commercial Chassis | All Trims | All Engines |
