Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 58507 |
Part Description | A C Compressor With Clutch |
Belt Width IN | 0.500 |
Clutch Included | Yes |
Clutch Maximum Diameter | 5.125 |
Coil Clock Position | Wire Lead |
Coil Voltage | 12 |
Comp Head Prt Config | Top-Vert O-Ring |
Compatible Refrigerant Oil Type | PAG 100 |
Compressor Head Type | FG/FV |
Compressor Type | SD510HD |
Discharge Port Type | O-Ring |
Distance From Clutch To Mounting Flange | 0.953125 |
Mount Distance B IN | 1.546875 |
Mounting Hardware | Not Included |
Mounting Type | Ear Mount |
New or Reman | New |
O-Ring A Number/Desc | [24608] / Green O-Ring |
O-Ring A Quantity | 1 |
O-Ring B Number/Desc | [24610] / Green O-Ring |
O-Ring B Quantity | 1 |
Pulley Belt Type | Serpentine |
Pulley Diameter MM | 130.048 |
Pulley Groove Quantity | 2 |
Pulley Lip Diameter | 5.125 |
Pulley Outside Diameter | 5.125 |
Pulley Ridge Diameter | 5.125 |
Refrigerant Type | R134a |
Suction Port Type | O-Ring |
Terminal Type | Bullet |
UPC | 096361585072 |
Year Make Model | Trim | Engine |
---|---|---|
1982-1984 Volvo 244 | All Trims | 6 Cyl 2.4L |
1982-1984 Volvo 245 | All Trims | 6 Cyl 2.4L |
1985-1986 Volvo 740 | All Trims | 6 Cyl 2.4L |
1985 Volvo 745 | All Trims | 6 Cyl 2.4L |
1983-1985 Volvo 760 | All Trims | 6 Cyl 2.4L |
