Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 58338 |
Part Description | A C Compressor With Clutch |
Clutch Included | Yes |
Clutch Maximum Diameter | 4.250 |
Coil Clock Position | Wire Lead |
Coil Voltage | 12 |
Compatible Refrigerant Oil Type | PAG 46 |
Compressor Type | 10P17C |
Discharge Port Type | Pad Mount |
Distance From Clutch To Mounting Flange | 2.296875 |
Mount Distance MM | 58.420 |
Mounting Hardware | Not Included |
Mounting Type | Tangent Mount |
New or Reman | New |
O-Ring A Number/Desc | [24613] / Green O-Ring |
O-Ring A Quantity | 4 |
O-Ring B Number/Desc | Not Required |
O-Ring B Quantity | NR |
O-Ring C Number/Desc | Not Required |
O-Ring C Quantity | NR |
Printed Foot Note | May Require use of OE Manifold |
Pulley Belt Type | V-Belt |
Pulley Diameter MM | 107.950 |
Pulley Groove Quantity | 1 |
Pulley Lip Diameter | 4.250 |
Pulley Outside Diameter | 4.250 |
Pulley Ridge Diameter | 4.250 |
Refrigerant Type | R134a |
Suction Port Type | Pad Mount |
Switch Included | Speed Sensor |
Terminal Type | Bullet |
UPC | 096361583382 |
w/ Diode | Yes |
Year Make Model | Trim | Engine |
---|---|---|
1989-1991 Audi 100 | All Trims | All Engines |
1993-1994 Audi 100 | All Trims | All Engines |
1989-1991 Audi 100 Quattro | All Trims | All Engines |
1993-1994 Audi 100 Quattro | All Trims | All Engines |
1989-1991 Audi 200 | All Trims | All Engines |
1989-1991 Audi 200 Quattro | All Trims | All Engines |
1985-1986 Audi 5000 | All Trims | 5 Cyl 2.2L |
1987-1988 Audi 5000 | All Trims | All Engines |
1986 Audi 5000 Quattro | All Trims | 5 Cyl 2.2L |
1987-1988 Audi 5000 Quattro | All Trims | All Engines |
