Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 58228 |
Part Description | A C Compressor With Clutch |
Clutch Included | Yes |
Clutch Maximum Diameter | 5.000 |
Coil Clock Position | 9 |
Coil Voltage | 12 |
Compatible Refrigerant Oil Type | PAG 150 |
Compressor Type | R4 Heavy |
Distance From Clutch To Mounting Flange | 1.203125 |
Mounting Hardware | Not Included |
Mounting Type | Case Mount |
New or Reman | New |
O-Ring A Number/Desc | [24359] / Short Sealing Washer Pilot |
O-Ring A Quantity | 1 |
O-Ring B Number/Desc | [24360] / Long Sealing Washer Pilot |
O-Ring B Quantity | 1 |
O-Ring C Number/Desc | [24356] / Red Sealing Washer |
O-Ring C Quantity | 2 |
O-Ring D Number/Desc | [24357] / Green Sealing Washer |
O-Ring D Quantity | 1 |
Printed Foot Note | Due to new enhancements, compressor may differ in appearance from OE Please refer to installation kit provided w/ each compressor. |
Pulley Belt Type | V-Belt |
Pulley Diameter MM | 127.000 |
Pulley Groove Quantity | 1 |
Pulley Lip Diameter | 5.000 |
Pulley Outside Diameter | 5.000 |
Pulley Ridge Diameter | 5.000 |
Refrigerant Type | R134a |
Reman w/o Clutch | [57019] |
Suc Prt Typ Note | Block |
Suction Port Type | O-Ring / Sealing Washer |
Switch Included | High Pressure |
Terminal Type | Spade |
UPC | 096361582286 |
Year Make Model | Trim | Engine |
---|---|---|
1986-1987 Buick Regal | All Trims | 8 Cyl 5.0L |
1980-1981 Buick Skylark | All Trims | 4 Cyl 2.5L |
1987 Chevrolet Camaro | All Trims | 6 Cyl 2.8L |
1987 Chevrolet Camaro | All Trims | 8 Cyl 5.0L |
1986-1988 Chevrolet Caprice | All Trims | 8 Cyl 5.7L |
1986-1990 Chevrolet Caprice | All Trims | 8 Cyl 5.0L |
1980-1983 Chevrolet Citation | All Trims | 4 Cyl 2.5L |
1986-1987 Chevrolet El Camino | All Trims | All Engines |
1986 Chevrolet Monte Carlo | All Trims | All Engines |
1987 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.8L |
