Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 58033 |
Part Description | A C Compressor With Clutch |
Belt Width IN | 0.500 |
Clutch Included | Yes |
Clutch Maximum Diameter | 5.250 |
Coil Clock Position | Wire Lead |
Coil Voltage | 12 |
Comp Head Prt Config | Top-Vert-Flare |
Compatible Refrigerant Oil Type | PAG 100 |
Compressor Head Type | B |
Compressor Type | SD508 |
Discharge Port Type | O-Ring |
Distance From Clutch To Mounting Flange | 0.953125 |
Mount Distance B IN | 1.546875 |
Mounting Hardware | Not Included |
Mounting Type | Ear Mount |
New or Reman | New |
O-Ring A Number/Desc | Not Required |
O-Ring A Quantity | NR |
O-Ring B Number/Desc | Not Required |
O-Ring B Quantity | NR |
O-Ring C Number/Desc | Not Required |
O-Ring C Quantity | NR |
Pulley Belt Type | Serpentine |
Pulley Diameter MM | 133.350 |
Pulley Groove Quantity | 2 |
Pulley Lip Diameter | 5.250 |
Pulley Outside Diameter | 5.250 |
Pulley Ridge Diameter | 5.250 |
Refrigerant Type | R134a |
Reman w/o Clutch | [57083] / Clutch Assembly |
Suction Port Type | O-Ring |
Terminal Type | Bullet |
UPC | 096361580336 |
Year Make Model | Trim | Engine |
---|---|---|
1982-1989 Alfa Romeo Spider | All Trims | All Engines |
1979-1982 Mazda 626 | All Trims | All Engines |
1974-1977 Mazda 808 | All Trims | All Engines |
1976 Mazda B1600 | All Trims | All Engines |
1977-1978 Mazda B1800 | All Trims | All Engines |
1979-1981 Mazda B2000 | All Trims | All Engines |
1976-1978 Mazda Cosmo | All Trims | All Engines |
1977-1982 Mazda GLC | All Trims | All Engines |
1971-1974 Mazda RX-2 | All Trims | All Engines |
1972-1978 Mazda RX-3 | All Trims | All Engines |
