Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 178312 |
Part Description | A C Compressor With Clutch |
Clutch Included | Yes |
Clutch Maximum Diameter | 4.500 |
Coil Clock Position | Lead Wire |
Coil Voltage | 12 |
Compatible Refrigerant Oil Type | PAG 46 |
Compressor Type | 6SES14C |
Discharge Port Type | O-Ring |
Distance From Clutch To Mounting Flange | 1.90625 |
ECV Harness Connector | SE25F, 26897 Female / / SE23M, 26883 Male |
Mounting Hardware | Not Included |
Mounting Type | Tangent Mount |
New or Reman | New |
O-Ring A Number/Desc | [24661] / Green O-Ring |
O-Ring A Quantity | 1 |
O-Ring B Number/Desc | [24681] / Green O-Ring |
O-Ring B Quantity | 1 |
Pulley Belt Type | Serpentine |
Pulley Groove Quantity | 6 |
Pulley Lip Diameter | 4.500 |
Pulley Outside Diameter | 4.500 |
Pulley Ridge Diameter | 4.500 |
Refrigerant Type | R134a |
Suction Port Type | O-Ring |
Terminal Type | Pin |
UPC | 096361032965 |
Year Make Model | Trim | Engine |
---|---|---|
2015 Hyundai Sonata | Limited 2.0T | 4 Cyl 2.0L |
2015 Hyundai Sonata | Sport 2.0T | 4 Cyl 2.0L |
2015 Hyundai Sonata | Limited | 4 Cyl 2.4L |
2015 Hyundai Sonata | SE | 4 Cyl 2.4L |
2015 Hyundai Sonata | Sport | 4 Cyl 2.4L |
2015-2017 Hyundai Sonata | All Trims | 4 Cyl 2.0L |
2015-2017 Hyundai Sonata | All Trims | 4 Cyl 2.4L |
