Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 158356 |
Part Description | A C Compressor With Clutch |
Clutch Included | Yes |
Clutch Maximum Diameter | 4.500 |
Coil Clock Position | Wire Lead |
Coil Voltage | 12 |
Compatible Refrigerant Oil Type | PAG 46 |
Compressor Type | 7SBU16C |
Discharge Port Type | O-Ring |
Distance From Clutch To Mounting Flange | 0.9375 |
Mount Distance MM | 23.622 |
Mounting Hardware | Not Included |
Mounting Type | Tangent Mount |
New or Reman | New |
O-Ring A Number/Desc | [24659] / Green O-Ring |
O-Ring A Quantity | 1 |
O-Ring B Number/Desc | [24635] / Green Round O-Ring |
O-Ring B Quantity | 1 |
Printed Foot Note | May Require use of OE Manifold |
Pulley Belt Type | Serpentine |
Pulley Diameter MM | 114.300 |
Pulley Groove Quantity | 6 |
Pulley Lip Diameter | 4.500 |
Pulley Outside Diameter | 4.500 |
Pulley Ridge Diameter | 4.500 |
Refrigerant Type | R134a |
Suction Port Type | O-Ring |
Terminal Type | Pin |
UPC | 096361616929 |
Year Make Model | Trim | Engine |
---|---|---|
2012-2013 BMW 328i | All Trims | 6 Cyl 3.0L |
2012-2013 BMW 328i xDrive | All Trims | 6 Cyl 3.0L |
1998-2001 BMW 750iL | All Trims | All Engines |
2010 BMW X1 | All Trims | 6 Cyl 3.0L |
2006-2010 BMW X3 | All Trims | 6 Cyl 3.0L |
2008 BMW X5 | All Trims | 6 Cyl 3.0L |
2010 BMW X5 | All Trims | 6 Cyl 3.0L |
2008 BMW X6 | All Trims | 6 Cyl 3.0L |
2010 BMW X6 | All Trims | 6 Cyl 3.0L |
