Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Dorman |
Part Number | 2630313 |
Part Description | Fuel Tank Sending Unit |
Connector Color | White |
Connector Gender | Female |
Connector Shape | Flat Plug |
Height | 230 mm |
Housing Length | 174 mm |
Housing Material | Plastic (Polybutylene Terephthalate) |
Housing Width | 94 mm |
Inlet Diameter | 7.89 mm |
Inlet Type | Female |
Length | 30 mm |
Lock Ring Included | No |
Maximum Flow Rating | 117 LPH |
Maximum Pressure | 0.8 MPA |
UPC | 747214016440 |
OE Part Number | 88957239, 22631715, 22683260, 22674713, 22709331 |
Outlet Diameter | 9.49 mm |
Outlet Quantity | 1 |
Outlet Type | Female |
Seal Included | Yes |
Terminal Gender | Male Female |
Terminal Quantity | 4 |
Terminal Type | Spade |
Top Mount Diameter | 6.35 mm |
Universal Or Specific Fit | Specific |
Width | 6.35 mm |
Wire Gauge Measurement | 1.5 AWG |
Wire Quantity | 4 |
Year Make Model | Trim | Engine |
---|---|---|
2000-2005 Chevrolet Cavalier | All Trims | All Engines |
2004-2005 Chevrolet Classic | All Trims | All Engines |
2000-2003 Chevrolet Malibu | All Trims | All Engines |
2000-2004 Oldsmobile Alero | All Trims | All Engines |
2000-2005 Pontiac Grand Am | All Trims | All Engines |
2000-2005 Pontiac Sunfire | All Trims | All Engines |
