Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Delphi |
Part Number | FG2080 |
Part Description | Fuel Pump Module Assembly |
Current Draw | 10 |
Flow Rating | 27 gph |
Fuel Level Sender Assembly Included | Yes |
Fuel Type | Gas |
Gasket or Seal Included | No |
Inlet Type | Strainer |
Internal or External Strainer | Internal |
Item Grade | Standard Replacement |
Outlet Outside Diameter | 0.375'' |
Outlet Quantity | 1 |
Outlet Type | Quick Connect |
Pump Type | Electric |
Regulator Included | Yes |
Resistance Ohms Empty | 53.0 |
Resistance Ohms Full | 290.0 |
Strainer Included | Yes |
System Pressure | 87 psi |
Terminal Gender | Male |
Terminal Quantity | 5 |
Terminal Type | Blade |
UPC | 689604284933 |
Vapor Pressure Sensor | No |
Voltage | 12.0 VDC |
Year Make Model | Trim | Engine |
---|---|---|
2015-2016 Audi A3 | All Trims | 4 Cyl 1.8L |
2017-2019 Audi A3 | All Trims | 4 Cyl 2.0L |
2015-2018 Volkswagen GTI | All Trims | 4 Cyl 2.0L |
2015-2018 Volkswagen Golf | All Trims | 4 Cyl 1.8L |
2015-2016 Volkswagen Golf SportWagen | All Trims | 4 Cyl 1.8L |
2017-2018 Volkswagen Golf SportWagen | S | 4 Cyl 1.8L |
2017-2018 Volkswagen Golf SportWagen | SE | 4 Cyl 1.8L |
2017-2018 Volkswagen Golf SportWagen | SEL | 4 Cyl 1.8L |
