Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Delphi |
Part Number | FG1705 |
Part Description | Fuel Pump Module Assembly |
Average Current Draw | 10 |
Average Flow Rating | 44 |
Fuel Level Sender Assembly Included | Yes |
Fuel Type | Gas |
Gasket or Seal Included | No |
In Tank or External | In Tank |
Inlet Type | Strainer |
Internal or External Strainer | Internal |
Item Grade | Standard Replacement |
Lock Ring Included | No |
Outlet Outside Diameter | 0.313 |
Outlet Quantity | 2 |
Outlet Type | Quick Connect |
Package Contents | Fuel Pump Module Assembly w/Float Arm, Instruction Sheet |
Pump Type | Electric |
Regulator Included | No |
Resistance Ohms Empty | 28.0 |
Resistance Ohms Full | 427.0 |
Strainer Included | Yes |
System Pressure | 51 psi |
Terminal Gender | Male |
Terminal Quantity | 6 |
Terminal Type | Pin |
UPC | 689604285121 |
Vapor Pressure Sensor | No |
Voltage | 12.0 |
Year Make Model | Trim | Engine |
---|---|---|
2003-2005 Land Rover Range Rover | All Trims | 8 Cyl 4.4L |
