Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Delphi |
Part Number | FG1664 |
Part Description | Fuel Pump Module Assembly |
Current Draw | 10 |
Flow Rating | 80 gph |
Fuel Level Sender Assembly Included | Yes |
Fuel Type | Diesel |
Gasket or Seal Included | Yes |
In Tank or External | In Tank |
Inlet Type | Strainer |
Internal or External Strainer | External |
Item Grade | Standard Replacement |
Maximum Pressure | 94.0 PSI |
Outlet Outside Diameter | 0.375'' |
Outlet Quantity | 3 |
Outlet Type | Quick Connect |
Pump Type | Electric |
Regulator Included | No |
Resistance Ohms Empty | 990.0 |
Resistance Ohms Full | 50.0 |
Strainer Included | Yes |
System Pressure | 20 psi |
Terminal Gender | Male |
Terminal Quantity | 4 |
Terminal Type | Blade |
UPC | 689604266670 |
Vapor Pressure Sensor | No |
Voltage | 12.0 VDC |
Year Make Model | Trim | Engine |
---|---|---|
2011-2012 Ram 3500 | ST | 6 Cyl 6.7L |
2011-2018 Ram 3500 | Laramie | 6 Cyl 6.7L |
2011-2018 Ram 3500 | SLT | 6 Cyl 6.7L |
2014 Ram 3500 | Tradesman | 6 Cyl 6.7L |
2016-2018 Ram 3500 | Tradesman | 6 Cyl 6.7L |
