Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Dayco |
Part Number | PBO81190SC10 |
Part Description | SUPERCHARGER PERF BALANCER, POWERBOND |
Bolt Hole Quantity | 9 |
Counterweight Balance | Neutral, no counterweight |
Crank Bore | 1.481 or 37.60 |
Crank Trigger/Exciter Plate | No |
Hardware Included | No |
Installation Instructions Included | Yes |
Nose Outside Diameter | 2.126 or 54.00 |
Number of Integrated Pulleys | 2 |
Outer Ring Material | Steel |
Overall Outside Diameter | 214.00 or 8.426 |
Overall Width | 117.50 or 4.626 |
Pulley 1 Number Of Grooves | 4 |
Pulley 1 Outside Diameter | 191.200 or 7.528 |
Pulley 1 Type | Serpentine |
Pulley 2 Number Of Grooves | 8 |
Pulley 2 Outside Diameter | 210.000 or 8.268 |
Pulley 2 Type | Serpentine |
Ring Width | 2.569 or 65.23 |
Timing Marks | Yes |
Woodruff Key Included | No |
Year Make Model | Trim | Engine |
---|---|---|
2004-2007 Buick Rainier | All Trims | 8 Cyl 5.3L |
2002-2005 Cadillac Escalade | All Trims | 8 Cyl 5.3L |
2002-2005 Cadillac Escalade | All Trims | 8 Cyl 6.0L |
2006-2008 Cadillac Escalade | All Trims | All Engines |
2007-2014 Cadillac Escalade | All Trims | 8 Cyl 6.2L |
2009-2013 Cadillac Escalade | All Trims | 8 Cyl 6.0L |
2014 Cadillac Escalade | All Trims | All Engines |
2003-2014 Cadillac Escalade ESV | All Trims | All Engines |
2007-2014 Cadillac Escalade ESV | All Trims | 8 Cyl 6.2L |
2002-2013 Cadillac Escalade EXT | All Trims | All Engines |
