Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Dayco |
Part Number | PB1091N |
Part Description | PREMIUM OEM REPL BALANCER, POWERBOND |
Bolt Hole Quantity | 4 |
Counterweight Balance | Neutral, no counterweight |
Crank Bore | 1.221 or 31.01 |
Crank Trigger/Exciter Plate | No |
Hardware Included | No |
Installation Instructions Included | No |
Nose Outside Diameter | 1.770 or 44.95 |
Number of Integrated Pulleys | 2 |
Outer Ring Material | Cast Iron |
Overall Outside Diameter | 154.50 or 6.083 |
Overall Width | 2.284 or 58.00 |
Pulley 1 Number Of Grooves | 1 |
Pulley 1 Outside Diameter | 136.500 or 5.375 |
Pulley 1 Type | V-Belt |
Pulley 2 Number Of Grooves | 1 |
Pulley 2 Outside Diameter | 151.500 or 5.965 |
Pulley 2 Type | V-Belt |
Ring Width | 0.828 or 21.03 |
Timing Marks | Yes |
Woodruff Key Included | No |
Year Make Model | Trim | Engine |
---|---|---|
1984-1987 Toyota 4Runner | All Trims | All Engines |
1988-1995 Toyota 4Runner | All Trims | 4 Cyl 2.4L |
1977-1978 Toyota Celica | All Trims | All Engines |
1979-1980 Toyota Celica | All Trims | 4 Cyl 2.2L |
1981-1985 Toyota Celica | All Trims | 4 Cyl 2.4L |
1978-1980 Toyota Corona | All Trims | All Engines |
1982 Toyota Corona | All Trims | All Engines |
1978-1980 Toyota Pickup | All Trims | All Engines |
1981-1995 Toyota Pickup | All Trims | 4 Cyl 2.4L |
