Check if it fits by entering your vehicle infoBrand | Autobest |
Part Number | F4873A |
Part Description | Fuel Pump Module Assembly |
Average Current Draw(A) | 8.5 |
Average Flow Rating(GPH) | 38.3 |
Connector Gender | Male |
Connector Quantity | 1 |
Connector Shape | Rectangle |
Country of Orign | China |
Fuel Filter Included | Yes |
Fuel Sending Unit Included | Yes |
Fuel Tank Pressure Sensor Included | No |
Gasket or Seal Included | Yes |
Gasket Or Seal Material | NBR |
Grade Type | Regular |
Housing Material | POM |
In Tank or External | In Tank |
Inlet Size | 0.433 |
Inlet Type | Strainer |
Installation Warnings | No |
Internal Or External Strainer | Internal |
Lock Ring Included | No |
Maximum Pump Pressure (PSI) | 55 |
Minimum Pump Pressure (PSI) | 55 |
Mounting Hardware Included | No |
Negative Ground | No |
Outlet Quantity | 1 |
Outlet Size | 3/8 |
Outlet Type | Quick Connect |
Product Height (in) | 6.3 |
Product Length (in) | 15.94 |
Product Width (in) | 7.48 |
Pump Type | Turbine |
Regulator Included | Yes |
Resistance Ohms Empty | 8 |
Resistance Ohms Full | 83 |
Strainer Included | Yes |
Terminal Gender | Male |
Terminal Quantity | 5 |
Terminal Type | PIN |
UPC | 00072845148735 |
Voltage | 12V |
Weight (lbs) | 2.9 |
Wire Harness Included | No |
Year Make Model | Trim | Engine |
---|---|---|
2007-2015 Nissan Armada | All Trims | 8 Cyl 5.6L |
2012-2018 Nissan NV1500 | All Trims | 6 Cyl 4.0L |
2012-2017 Nissan NV2500 | All Trims | 8 Cyl 5.6L |
2012-2018 Nissan NV2500 | All Trims | 6 Cyl 4.0L |
2012-2017 Nissan NV3500 | All Trims | 8 Cyl 5.6L |
2012-2018 Nissan NV3500 | All Trims | 6 Cyl 4.0L |
2005-2015 Nissan Titan | All Trims | 8 Cyl 5.6L |
