Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Autobest |
Part Number | F2703A |
Part Description | Fuel Pump Module Assembly |
Average Current Draw(A) | 7 |
Average Flow Rating(GPH) | 26.1 |
Connector Gender | Male |
Connector Quantity | 1 |
Connector Shape | Racetrack |
Country of Orign | China |
Fuel Filter Included | Yes |
Fuel Sending Unit Included | Yes |
Fuel Tank Pressure Sensor Included | Yes |
Fuel Type | Turbine |
Gasket or Seal Included | Yes |
Gasket Or Seal Material | NBR |
Grade Type | Performance |
Housing Material | POM |
In Tank or External | In Tank |
Inlet Size | 0.433 |
Inlet Type | Strainer |
Installation Warnings | No |
Internal or External | Internal |
Internal Or External Strainer | Internal |
Lock Ring Included | Yes |
Maximum Free Flow (GPH) | 63.5 |
Maximum Pump Pressure (PSI) | 64 |
Minimum Free Flow (GPH) | 52.8 |
Minimum Pump Pressure (PSI) | 59 |
Negative Ground | Yes |
Outlet Quantity | 1 |
Outlet Size | 0.373 |
Outlet Type | Quick Connect |
Product Height (in) | 7.76 |
Product Length (in) | 11.89 |
Product Width (in) | 8.11 |
Pump Type | Turbine |
Regulator Included | Yes |
Resistance Ohms Empty | 42 |
Resistance Ohms Full | 253 |
Strainer Included | Yes |
Terminal Gender | Male |
Terminal Quantity | 4 |
Terminal Type | PIN |
UPC | 00072845127037 |
Voltage | 12V |
Weight (lbs) | 3.51 |
Wire Harness Included | No |
Year Make Model | Trim | Engine |
---|---|---|
2007 Buick Allure | All Trims | 6 Cyl 3.6L |
2007-2008 Buick Allure | All Trims | 6 Cyl 3.8L |
2007 Buick LaCrosse | All Trims | 6 Cyl 3.6L |
2007-2008 Buick LaCrosse | All Trims | 6 Cyl 3.8L |
2007 Chevrolet Impala | All Trims | 6 Cyl 3.9L |
2007-2008 Chevrolet Impala | All Trims | 6 Cyl 3.5L |
2007 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.5L |
2007-2008 Pontiac Grand Prix | All Trims | 6 Cyl 3.8L |
