Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Autobest |
Part Number | F4301 |
Part Description | Fuel Pump And Strainer Set |
Average Current Draw(A) | 16 |
Average Flow Rating(GPH) | 100 |
Connector Gender | Female |
Connector Quantity | 1 |
Country of Orign | China |
Gasket or Seal Included | Yes |
Gasket Or Seal Material | FKM |
In Tank or External | In Tank |
Inlet Type | Strainer |
Installation Warnings | No |
Lock Ring Included | No |
Maximum Pump Pressure (PSI) | 188.5 |
Minimum Pump Pressure (PSI) | 145 |
Negative Ground | Yes |
Outlet Quantity | 1 |
Outlet Size | M12 × 10.5 |
Outlet Type | Threaded Male |
Product Height (in) | 2.46 |
Product Length (in) | 7.87 |
Product Width (in) | 2.46 |
Pump Type | Turbine |
Regulator Included | No |
Strainer Included | Yes |
Terminal Gender | Female |
Terminal Quantity | 2 |
Terminal Type | Wire |
UPC | 00072845143013 |
Voltage | 12V |
Weight (lbs) | 1.58 |
Wire Harness Included | Yes |
Year Make Model | Trim | Engine |
---|---|---|
1985 Audi 5000 | CS Turbo | 5 Cyl 2.2L |
1985 Audi 5000 | S | 5 Cyl 2.2L |
1985 Audi 5000 | S Turbo | 5 Cyl 2.2L |
1986 Audi 5000 | All Trims | 5 Cyl 2.2L |
1987-1988 Audi 5000 | CS | 5 Cyl 2.2L |
1987-1988 Audi 5000 | All Trims | 5 Cyl 2.3L |
