Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Autobest |
Part Number | F4542A |
Part Description | Electric Fuel Pump |
Average Current Draw(A) | 6 |
Average Flow Rating(GPH) | 34.2 |
Connector Gender | Male |
Connector Quantity | 1 |
Connector Shape | Rectangle |
Country of Orign | China |
Fuel Filter Included | No |
Fuel Sending Unit Included | Yes |
Fuel Tank Pressure Sensor Included | No |
Gasket or Seal Included | No |
Grade Type | Performance |
Housing Material | POM |
In Tank or External | In Tank |
Inlet Size | 0.441 |
Inlet Type | Strainer |
Installation Warnings | No |
Internal Or External Strainer | Internal |
Lock Ring Included | No |
Maximum Pump Pressure (PSI) | 120 |
Minimum Pump Pressure (PSI) | 110 |
Negative Ground | Yes |
Outlet Quantity | 1 |
Outlet Size | 5/16 |
Outlet Type | Hose Bead |
Product Height (in) | 6.57 |
Product Length (in) | 10.75 |
Product Width (in) | 7.13 |
Pump Type | Turbine |
Regulator Included | No |
Resistance Ohms Empty | 990 |
Resistance Ohms Full | 50 |
Strainer Included | Yes |
Terminal Gender | Male |
Terminal Quantity | 4 |
Terminal Type | Inserts |
UPC | 00072845145420 |
Voltage | 12V |
Weight (lbs) | 2.24 |
Wire Harness Included | No |
Year Make Model | Trim | Engine |
---|---|---|
2007 Mercedes-Benz C230 | All Trims | 6 Cyl 2.5L |
2006-2007 Mercedes-Benz C350 | All Trims | 6 Cyl 3.5L |
2006-2009 Mercedes-Benz CLK350 | All Trims | 6 Cyl 3.5L |
2003-2006 Mercedes-Benz CLK500 | All Trims | 8 Cyl 5.0L |
