Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Autobest |
Part Number | F2740 |
Part Description | Electric Fuel Pump |
Average Current Draw(A) | 9.5 |
Average Flow Rating(GPH) | 41 |
Connector Gender | Female |
Connector Quantity | 1 |
Connector Shape | Rectangle |
Country of Orign | China |
Fuel Filter Included | No |
Fuel Sending Unit Included | No |
Fuel Tank Pressure Sensor Included | No |
Gasket or Seal Included | Yes |
Gasket Or Seal Material | FKM |
Grade Type | Regular |
In Tank or External | In Tank |
Inlet Size | 0.748 |
Inlet Type | Strainer |
Installation Warnings | No |
Internal Or External Strainer | Internal |
Lock Ring Included | No |
Maximum Pump Pressure (PSI) | 90 |
Minimum Pump Pressure (PSI) | 80 |
Mounting Hardware Included | No |
Negative Ground | No |
Outlet Quantity | 1 |
Outlet Size | 5/16 |
Outlet Type | Quick Connect |
Product Height (in) | 2.36 |
Product Length (in) | 10.63 |
Product Width (in) | 3.23 |
Pump Type | Turbine |
Regulator Included | No |
Strainer Included | Yes |
Terminal Gender | Male |
Terminal Quantity | 2 |
Terminal Type | PIN |
UPC | 00072845167408 |
Voltage | 12V |
Weight (lbs) | 1.49 |
Wire Harness Included | No |
Year Make Model | Trim | Engine |
---|---|---|
1996-1997 Chevrolet Camaro | All Trims | 6 Cyl 3.8L |
1996-1997 Chevrolet Camaro | All Trims | 8 Cyl 5.7L |
1996-1997 Pontiac Firebird | All Trims | 6 Cyl 3.8L |
1996-1997 Pontiac Firebird | All Trims | 8 Cyl 5.7L |
