Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Autobest |
Part Number | F2693A |
Part Description | Electric Fuel Pump |
Average Current Draw(A) | 7.5 |
Average Flow Rating(GPH) | 38 |
Connector Gender | Male |
Connector Quantity | 1 |
Connector Shape | Racetrack |
Country of Orign | China |
Fuel Filter Included | Yes |
Fuel Sending Unit Included | Yes |
Fuel Tank Pressure Sensor Included | No |
Fuel Type | Turbine |
Gasket or Seal Included | No |
Grade Type | Performance |
Height (in.) | 7 |
Housing Material | POM |
In Tank or External | In Tank |
Inlet Size | 0.314 |
Inlet Type | Strainer |
Installation Warnings | No |
Internal Or External Strainer | Internal |
Length (in.) | 18 |
Life Cycle Status Code | Available to Order |
Lock Ring Included | Yes |
Maximum Pump Pressure (PSI) | 115 |
Minimum Pump Pressure (PSI) | 100 |
Negative Ground | Yes |
Outlet Quantity | 1 |
Outlet Size | 3/8 |
Outlet Type | Quick Connect |
Package Contents | Fuel Pump Module Assembly |
Product Height (in) | 8.11 |
Product Length (in) | 15.39 |
Product Width (in) | 8.66 |
Regulator Included | Yes |
Resistance Ohms Empty | 40 |
Resistance Ohms Full | 252 |
Short Description | Electric Fuel Pump |
Strainer Included | Yes |
Terminal Gender | Male |
Terminal Quantity | 4 |
Terminal Type | PIN |
UPC | 00072845126931 |
Voltage | 12V |
Weight (lbs) | 4.15 |
Weight (lbs.) | 5.262 |
Width (in.) | 11 |
Wire Harness Included | No |
Year Make Model | Trim | Engine |
---|---|---|
2004-2005 Chevrolet Express 3500 | All Trims | 8 Cyl 6.0L |
2005 Chevrolet Express 3500 | All Trims | 8 Cyl 4.8L |
2004-2005 GMC Savana 3500 | All Trims | 8 Cyl 6.0L |
2005 GMC Savana 3500 | All Trims | 8 Cyl 4.8L |
