Notes: with 26 Gallon Tank;Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
Current Draw: 8
Flow Rating: 32 gph
Fuel Level Sender Assembly Included: Yes
Fuel Type: Gas
Gasket or Seal Included: Yes
In Tank or External: In Tank
Inlet Type: Strainer
Internal or External Strainer: External
Item Grade: Standard Replacement
Maximum Pressure: 80.0 PSI
Outlet Outside Diameter: 0.375''
Outlet Quantity: 1
Outlet Type: Quick Connect
Pump Type: Electric
Regulator Included: Yes
Resistance Ohms Empty: 220.0
Resistance Ohms Full: 20.0
Strainer Included: Yes
System Pressure: 58 psi
Terminal Gender: Male
Terminal Quantity: 4
Terminal Type: Blade
UPC: 689604237984
Vapor Pressure Sensor: No
Voltage: 12.0 VDC
Part Description: 2004 Dodge Ram 1500 Fuel Pump Module Assembly
Notes: with 35 Gallon Tank;Late;Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
Current Draw: 11
Flow Rating: 21 gph
Fuel Level Sender Assembly Included: Yes
Fuel Type: Gas
Gasket or Seal Included: Yes
In Tank or External: In Tank
Inlet Type: Strainer
Internal or External Strainer: Internal
Item Grade: Standard Replacement
Maximum Pressure: 78.0 PSI
Outlet Outside Diameter: 0.375''
Outlet Quantity: 1
Outlet Type: Quick Connect
Pump Type: Electric
Regulator Included: Yes
Resistance Ohms Empty: 220.0
Resistance Ohms Full: 20.0
Strainer Included: Yes
System Pressure: 58 psi
Terminal Gender: Male
Terminal Quantity: 4
Terminal Type: Blade
UPC: 689604203149
Vapor Pressure Sensor: No
Voltage: 12.0 VDC
Part Description: 2004 Dodge Ram 1500 Fuel Pump Module Assembly
Notes: with 34 Gallon Tank;Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
Current Draw: 11
Flow Rating: 21 gph
Fuel Level Sender Assembly Included: Yes
Fuel Type: Gas
Gasket or Seal Included: Yes
In Tank or External: In Tank
Inlet Type: Strainer
Internal or External Strainer: Internal
Item Grade: Standard Replacement
Maximum Pressure: 78.0 PSI
Outlet Outside Diameter: 0.375''
Outlet Quantity: 1
Outlet Type: Quick Connect
Pump Type: Electric
Regulator Included: Yes
Resistance Ohms Empty: 220.0
Resistance Ohms Full: 20.0
Strainer Included: Yes
System Pressure: 58 psi
Terminal Gender: Male
Terminal Quantity: 4
Terminal Type: Blade
UPC: 689604203132
Vapor Pressure Sensor: No
Voltage: 12.0 VDC
Part Description: 2004 Dodge Ram 1500 Fuel Pump Module Assembly
Notes: Includes Fuel Pump, Fuel Pressure Regulator, Sending Unit, Float, Fuel Reservoir, Fuel Strainer and Tank Seal;Long Bed;Short Bed;w/26 Gallon Tank;w/35 Gallon Tank
Gasket or Seal Included: Yes
Inlet Size: 0.314
Inlet Type: Strainer
Internal or External: Internal
Maximum Free Flow (GPH): 63.4
Maximum Pump Pressure (PSI): 62.35
Minimum Free Flow (GPH): 55.4
Minimum Pump Pressure (PSI): 59.45
Outlet Size: 0.374
Outlet Type: Quick Connect
Pump Type: Turbine
Regulator Included: No
UPC: 072845131911
Part Description: 2004 Dodge Ram 1500 Fuel Pump Module Assembly
Notes: with 26 Gallon Tank;Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
Current Draw: 11
Flow Rating: 21 gph
Fuel Level Sender Assembly Included: Yes
Fuel Type: Gas
Gasket or Seal Included: Yes
In Tank or External: In Tank
Inlet Type: Strainer
Internal or External Strainer: Internal
Item Grade: Standard Replacement
Maximum Pressure: 78.0 PSI
Outlet Outside Diameter: 0.313''
Outlet Quantity: 1
Outlet Type: Quick Connect
Pump Type: Electric
Regulator Included: Yes
Resistance Ohms Empty: 220.0
Resistance Ohms Full: 20.0
Strainer Included: Yes
System Pressure: 58 psi
Terminal Gender: Male
Terminal Quantity: 4
Terminal Type: Blade
UPC: 689604200520
Vapor Pressure Sensor: No
Voltage: 12.0 VDC
Part Description: 2004 Dodge Ram 1500 Fuel Pump Module Assembly
Notes: Short Bed;with 34 Gallon Tank;Includes Fuel Pump, Fuel Pressure Regulator, Sending Unit, Float, Fuel Reservoir, Fuel Strainer and Tank Seal;w/34 Gallon Tank
Gasket or Seal Included: Yes
Inlet Size: 0.314
Inlet Type: Strainer
Internal or External: Internal
Maximum Free Flow (GPH): 62
Maximum Pump Pressure (PSI): 62.35
Minimum Free Flow (GPH): 54.1
Minimum Pump Pressure (PSI): 59.45
Outlet Size: 0.374
Outlet Type: Quick Connect
Pump Type: Turbine
Regulator Included: No
UPC: 072845131935
Part Description: 2004 Dodge Ram 1500 Fuel Pump Module Assembly
